BP Pump 2
Operators Manual
1-8
Table 1-2. Top and Side Panel Components
Label Name Function
A Home Key Returns the operator to the Main Menu.
B Soft Keys 1 - 4
Makes dynamic assignments based on
the current screen.
C
Number (Test and
Simulations) Keys
Allows the operator to perform auto
sequences and simulations using
numeric keys.
D Enter Key
Advances to the next menu or
saves/selects options.
E Pulse Indicator
LED blinks in synchronization with
beeper, indicating that the pump is
generating a simulated blood pressure
pulse.
F ECG Interface Port Allows connection of optional ECG
accessory (refer to Appendix, ECG
Option).
G Printer Port Provides D-25 female connector for
external parallel printer.
H RS-232 Serial Port Provides serial D-9 female connector for
bi-directional computer control.
I Pressure Port
Connects to the Non-Invasive Blood
Pressure Monitor for all pressure
simulations and tests.
To Next Page
