Setup, Maintenance, and Support
Setting up the Tester
2
2-3
Setting up the Tester
To set up the tester, carry out the following:
1. Insert the power cord into the Tester and plug the cord into an appropriate
ac power socket.
W X Warning
To avoid possible electric shock, burning of the skin, or
personal injury, ensure that the external power source is
properly rated for the system.
2. Turn the power switch on. When the Tester is powered up, the Main
menu appears.
Fluke Biomedical BP Bump 2
SETUP
PRESSURE
TESTS
AUTO
SEQUENCE
PERFORM
SIMULATION
fas31.eps
3. The Tester has several configurable options available from the Setup
menu. You can reach the Setup menu by using the soft keys to follow
the menu path shown below:
MAIN MENU C SETUP
The Setup menu appears, showing the following configurable options:
BP Pump 2 Setup
MORE*
USER DEF
SIMULATION LANGUAGE
PRINTER
OUTPUT
fas37.eps
4. Press the MORE soft key in this and each of the following screens to
display additional options:
