BP Pump 2
Operators Manual
3-18
Respiratory Artifacts
The Respiratory Artifact exhibits a beat-to-beat variation in the blood pressure
caused by intra-thoracic pressure. Changes in the intra-thoracic pressure affect
filling of the ventricles during diastole. This in turn affects the stroke volume of
the heart. A large stroke develops a higher systolic pressure than a small stroke.
To perform Respiratory Artifact simulations, do the following:
1. Access these simulations by pressing the 7 RESPIRATORY ARTIFACT
key. The Respiratory Artifact screen appears.
Respiratory Artifact
Spont Breath # 1
Cuff: External
OPTIONS CUFF
ready ....
138/ 65 (89)
104 BPM
fas11.eps
2. Press the OPTIONS soft key to scroll through the simulation choices.
Parameters for Respiratory Artifact simulations are shown in Table 3-5.
Table 3-5. Respiratory Artifact Simulations
Artifact Type
Blood
Pressure
(mmHg) (MAP)
Heart Rate
(bpm)
Pulse
volume (cc)
Spontaneous Breathing #1 138/65 (89) 104 Varies
Spontaneous Breathing #2 149/65 (93) 105 Varies
Spontaneous Breathing #3 112/47 (68) 86 Varies
Controlled Ventilation 132/44 (73) 98 Varies
3. Press the CUFF soft key to select Internal Adult or External cuff.
4. Press Start on the NIBP unit.
5. Compare values on the NIBP unit with those on the Tester.
6. Press HOME to return to the Main menu.
