BP Pump 2
Operators Manual
2-4
BP Pump 2 Setup
MORE*
RS232
SETTINGS
SELF
TEST
UNITS OF
MEASURE
fas38.eps
BP Pump 2 Setup
MORE*
ENABLE
ECG
ZERO
PRESSURE
fas39.eps
Note
These parameters should be configured and the settings saved the
first time the Tester is used. They need to be configured only once.
Printer Output
Printouts are available for auto sequences. By default, the Printer Output is set
to NONE.
To control the production of when running auto sequences, take the following
actions:
1. Select the desired print format by using the soft keys to follow the menu
path shown below.
SETUP C PRINTER OUTPUT
The Printer Output screen appears, showing the available options:
Printer Output: None
A3CII HP PCL3 NONE
fas22.eps
2. Select one option and press ENT to return to the SETUP menu.
3. If desired, press HOME to return to the Main menu.
