Setup, Maintenance, and Support
Setting up the Tester
2
2-9
3. If desired, press HOME to return to the Main menu.
Enable ECG Signal
The ECG output is enabled or disabled by the operator. If the patient monitor
under test does not make use of ECG signals, we recommend that the ECG
output be disabled. (The factory default is for ECG to be disabled.) ECG
signals are present for all Standard BP, Patient Condition, and Arrhythmia
NIBP simulations. The ECG signals are present on the ECG Interface Port as
shown in Figure 1-2. An optional ECG Interface adapter, as described in
Appendix A, is available for purchase.
To enable or disable ECG signals, take the following actions:
1. Use the soft keys to follow the menu path shown below.
SETUP C *MORE C MORE C ENABLE ECG
The Enable ECG? screen appears, showing options YES and NO:
Enable ECG?
YES NO
Ye s
fas30.eps
2. Select one option and press ENT to return to the Setup menu.
3. If desired, press HOME to return to the Main menu.
