190 Series III
Users Manual
6
Tabl e 2 is a list of the included accessories that are specific to the MDA-550-III.
How to Use the Test Tool
This section provides a step-by-step introduction to the scope and meter functions of the test
tool. The introduction does not cover all of the capabilities of the functions but gives basic
examples to show how to use the menus and perform basic operations.
Test Tool Power
See Figure 1 to power the test tool from a standard ac outlet. See Battery Life for instructions on
using battery power.
Turn on the test tool with
O.
The test tool powers up in the last setup configuration.
The menus to adjust date, time, and information language are switched on automatically when
the test tool is powered on for the first time.
Table 2. MDA-550-III Accessories
Item Description
Set of 3 brushes
Probe holder with 2 extension rods
Magnetic base
