ScopeMeter
®
Test Tool
Memory and PC
59
WiFi Connection
You can connect the test tool with a WiFi USB Adapter to a computer, tablet, or smartphone that
has a wireless LAN interface. To support wireless communication, use the USB port to insert the
supported WiFi-USB adapter. See Figure 32.
To set up the test tool for use with a wireless connection:
1. Push F + 1 to turn on the WiFi.
shows in the Information area.
When prompted by the computer Network Settings or Fluke Connect™ app for a WiFi name
(SSID) to detect the test tool, select the model number followed by the serial number.
When prompted, use the password that is shown in the key label bar.
2. Use 2 to send a screenshot to the Fluke Connect™ app.
3. Push F + 1 to turn off WiFi.
no longer shows at the top of the screen in the
Information area.
Figure 32. Computer Connection
