Flyability ELIOS - Ground Control System

12
Figure 3.2: Elios overview
3.1.1 Battery and charging
LiPo batteries are very sensitive and dangerous devices.
Please read carefully the “Battery Handling, Recharge and Transport” manual available in the
my.flyability.com platform to know more about the proper use of the batteries.
3.2 Ground Control System
3.2.1 Controller
The controller gives to the pilot a full mechanical control of the aircraft. It is also used to set some
parameter on the payload and the lighting.
Figure 3.3: Pilot controller overview
