Flyability ELIOS - Specifications; Flight Performance and System Specs

51
9. Specification
Flight mode
Types
Manual thrust control
Automatic Altitude Control
High Speed Mode
Availability
Switch between modes at any time
Fail safe
Auto-landing on low-battery or signal lost
Flight system
Dimension
fits in <400mm sphere
Motors
4 electric brushless motors
Takeoff weight
700gr incl.battery, payload & protection
Flight time
Up to 10min
Max. Climb rate
1.5 m/s (in normal mode)
2.5 m/s (in high speed flight mode)
Max. airspeed
3 m/s (in normal mode)
7 m/s (in high speed flight mode)
Max. acceptable impact speed
3 m/s
Wind resistance
max 5m/s (in High Speed flight mode)
Sensor
Autopilot & control IMU, magnetometer, barometer
Materials
Carbon fiber composites, magnesium alloy, aeronautical grade
aluminium, High quality thermoplastics
Operating temperature
-10 to +35°C
Wireless communication
Type
Digital, bidirectional, long range Video and Data downlink to
RC, Command and Data uplink to UAV
Frequency
2.4GHz
Range
Up to 5km without any obstruction
Optional remote
Camera operator
Optional deported antenna
Amplified deported antenna system
System power
Type
Lithium polymer battery, 3 cells, 2800mAh, 33.08Wh
Charging time
1h
Battery change time
< 1 minute
Main camera
Video
FHD (1920 x 1080) at 30fps
Good low light performance
Recorded on board and streamed to pilot and camera operator
Tilting range
+90° up -45 ° down
Horizontal field of view
130 degrees
Vertical field of view
100 degrees
Total vertical field of view
235 degrees (considering payload up/down rotation)
Control modes
Auto with EV correction
full manual mode
Thermal camera
Video
60x120 pixels at 9fps, Recorded on board
Horizontal field of view
56 degrees
Vertical field of view
42 degrees
Lighting system
Type
LED, high efficiency
5 Arrays for even lighting in front, top and bottom of the robot
Adaptive light beam controlled by camera pitch, Intelligent auto mode
for best pictures and lowest work load
Control modes
Intelligent auto
