6.3 Cleaning the robot
After a mission, it is important to clean the robot. To do so, compressed air from a air blow gun or can can
be used. Pay a special attention to the motors. Dust or other particles may damage the motors if stuck
inside.
If you blow air on the motors, please wear gloves and hold the corresponding propeller.
The air flow may make spin the propeller.
Isopropanol alcohol can be use to clean the cage and any surfaces of the robot.
Avoid the use of water. It may damage the electronic.
6.4 Transport Elios
Elios should never be transported with a battery on it.
To avoid any movement of the robot during the transportation, Elios shall be attached to its cage. To do
so, follow these steps:
1. Make sure no battery are inside the aircraft
2. Close the battery strap
3. Pass the transportation strap through the battery strap, the ring and a pentagon as shown below.
Figure 6.2: Attaching inner frame to the cage
