FOR-A MFR Series Operation Manuals

50
6. Specifications and Dimensions
6-1. Unit Specifications
6-1-1. MFR-1616/1616R/3216/3216RPS/3232/3232RPS
MFR-1616
MFR-1616R
MFR-3216
MFR-3216RPS
MFR-3232
MFR-3232RPS
Video Formats
3G HD: 1080/60p, 1080/59.94p, 1080/50p
HD: 1080/60i, 1080/59.94i, 1080/50i, 1080/30p, 1080/30PsF,
1080/29.97p, 1080/29.97PsF, 1080/23.98p, 1080/23.98PsF, 1080/25p,
1080/25PsF, 1080/24PsF, 1080/24p, 720/60p, 720/59.94p, 720/50p
SD: 525/60, 625/50
Inputs x Outputs
16 x 16
16 x 16
32 x 16
32 x 32
Video Inputs
Compliant with the following standards (75Ω BNC):
-SMPTE424M (2.97 Gbps, 2.97/1.001 Gbps)
-SMPTE292M (1.485 Gbps, 1.485/1.001 Gbps)
-SMPTE259M (270 Mbps)
-DVB-ASI
Cable equalization
3G: 70 m (when a 5C-FB equivalent cable is used)
HD-SDI: 100 m (when a 5C-FB equivalent cable is used)
SD-SDI: 200 m (when a 5C-2V equivalent cable is used)
Video Outputs
Compliant with the following standards (75Ω BNC) (with automatic
reclocking):
-SMPTE424M (2.97 Gbps, 2.97/1.001 Gbps)
-SMPTE292M (1.485 Gbps, 1.485/1.001 Gbps)
-SMPTE259M (270 Mbps)
-DVB-ASI
Reference Inputs
BB: NTSC: 0.429 Vp-p/PAL: 0.45 Vp-p or Tri-level sync: ±0.3Vp-p 75Ω
BNC x 1, loop-through (Terminate with 75Ω terminator, if unused.)
Interfaces
MFR-LAN
10/100BASE-TX RJ-45 (for RU/GPI connection, up to 128 units)
x 1
x 2
(LAN 2: For MFR-SRCPU connection.)
PC-LAN
10/100BASE-TX RJ-45 x 1 (for computer or other external device
connection)
SERIAL
RS-232C/RS-422 (selectable by internal switches)
9-pin D-sub (male) x 1
ALARM
9-pin D-sub (female) x 1
TO RS
Unused
Temperature
0°C to 40°C
Humidity
30% to 90% (no condensation)
Power
100VAC to 240VAC ±10%, 50/60Hz
Power Consumption
100 V AC to 120 V AC
36 VA (33 W)
37 VA (34 W)
48 VA (45 W)
60 VA (54 W)
200 V AC to 240 V AC
44 VA (34 W)
44 VA (34 W)
57 VA (45 W)
70 VA (52 W)
Dimensions
430(W) x 44(H)
x 300(D) mm
EIA 1RU
430(W) x 88(H) x 300(D) mm EIA 2 RU
Weight
5 kg
5 kg
6 kg
6 kg
Consumables
Fan (P-1461) :
Replace every 4
years.
Fan (P-1460)
Replace every 4 years.
Power unit: Replace every 5 years.
