Page #51 background imageLoading...
Page #51 background image
51
6-1-2. MFR-1616A
Inputs x Outputs
16 stereo pairs (32 channels) × 16 stereo pairs (32 channels)
Audio Inputs
AES/EBU: 1.0Vp-p Unbalanced 75Ω BNC x 16
Audio Outputs
AES/EBU1.0Vp-p±10% Unbalanced 75Ω BNC x 16
Sampling Frequency
32kHz to 96kHz
Reference Input
BB: NTSC: 0.429 Vp-p/PAL: 0.45 Vp-p or Tri-level sync: ±0.3 Vp-p
75Ω BNC x 1, loop-through (Terminate with 75Ω terminator, if
unused.)
Interfaces
MFR-LAN
10/100BASE-TX RJ-45 x 1 (for RU/GPI connection, up to 128 units)
PC-LAN
10/100BASE-TX RJ-45 x 1 (for computer or other external device
connection)
RS-232C
RS-232C 9-pin D-sub (male) x 1
ALARM
9-pin D-sub (female) x 1
Temperature
0°C to 40°C
Humidity
30% to 90% (no condensation)
Power
100VAC to 240VAC ±10%, 50/60Hz
Power Consumption
19 VA (17 W) at 100 V AC to 120 V AC
24 VA (17 W) at 200 V AC to 240 V AC
Dimensions
430(W)×44(H)×300(D)mm EIA 1RU
Weight
5 kg
Consumables
Power unit: Replace every 5 years.
6-1-3. MFR-GPI
Number of
Connection
Max. 128 (including Main, Remote and GPI units)
Interface
MFR-LAN
10/100BASE-TX RJ-45 x 1
(Ethernet hub is needed for Main and multiple unit connections.)
SERVICE
RS-232C: 9-pin D-sub (male) x 1 (for maintenance)
GPI IN
/TALLY OUT
37-pin D-sub (female) x 4
128-input/output (user assignable)
SERIAL 1-4
RS-232C/422 (selectable): 9-pin D-sub (male) x 4
Temperature
0°C to 40°C
Humidity
30% to 85% (no condensation)
Power
+12VDC pin connector x 2 (redundant power supply in standard
configuration)
Power Consumption
100 V AC to 120 V AC: 8 VA (4 W)
200 V AC to 240 V AC: 13 VA (6 W)
Dimensions
430(W) x 44(H) x 110(D) mm EIA 1 RU
Weight
2 kg
