Manual - Formech 686PT - Rev 8.8
10
General Arrangement

5
4 6
2
3
71
1- Heater
2- Clamp Frame Handle
3- Toggle Clamps
4- Mitsubishi touch screen
5- ‘Table Up’ Control Buttons
6- Vacuum Gauge
7- Heater Handle
8- Heater Transit Lock
9- Heater Guard
10- Counter Balance Weights
11- Self-adjusting Clamps Springs
12- Control Box with Main Switch
13- Heater Rear Supports

