49

VFDGroupApplicationDefaults
Code
OLEDDisplay
Name
Basic SupplyFan ExhaustFan
Cooling
Tower
Surface/
BoosterPump
4 AutoBypass (0)Disabled  (0)Disabled (0)Disabled (0)Disabled (0)Disabled
6 DamperControl (0)Disabled (0)Disabled (0)Disabled (0)Disabled (0)Disabled
7 DamperDelay 120[sec] 120[sec] 120[sec] 120[sec] 120[sec]
10 SkipFreq1
Enable
(0)Disabled (0)Disabled (0)Disabled (0)Disabled (0)Disabled
11 SkipFreq1Low 23.00[Hz] 23.00[Hz] 23.00[Hz] 23.00[Hz] 23.00[Hz]
12 SkipFreq1High 26.00[Hz] 26.00[Hz] 26.00[Hz] 26.00[Hz] 26.00[Hz]
13 SkipFreq2
Enable
(0)Disabled (0)Disabled (0)Disabled (0)Disabled (0)Disabled
14 SkipFreq2Low 33.00[Hz] 33.00[Hz] 33.00[Hz] 33.00[Hz] 33.00[Hz]
15 SkipFreq2High 36.00[Hz] 36.00[Hz] 36.00[Hz] 36.00[Hz] 36.00[Hz]
16 SkipFreq3
Enable
(0)Disabled (0)Disabled (0)Disabled (0)Disabled (0)Disabled
17 SkipFreq3Low 43.00[Hz] 43.00[Hz] 43.00[Hz] 43.00[Hz] 43.00[Hz]
18 SkipFreq3High 46.00[Hz] 46.00[Hz] 46.00[Hz] 46.00[Hz] 46.00[Hz]
19 SpeedA 30.00[Hz] 30.00[Hz] 30.00[Hz] 30.00[Hz] 30.00[Hz]
20 SpeedB 35.00[Hz] 35.00[Hz] 35.00[Hz] 35.00[Hz] 35.00[Hz]
21 SpeedAB 40.00[Hz] 40.00[Hz] 40.00[Hz] 40.00[Hz] 40.00[Hz]
22 SetpointA 50.0[PSI] 1.10[inWC] 1.10[inWC] 75.5[°F] 50.0[PSI]
23 SetpointB 55.0[PSI] 1.20[inWC] 1.20[inWC] 76.5[°F] 55.0[PSI]
24 SetpointAB 65.0[PSI] 1.30[inWC] 1.30[inWC] 77.0[°F] 65.0[PSI]


