Franklin Q-link - I;O Terminals

80

8.4 I/O Terminals

I/O-1: D1-SG Function
D1-SG Function
1) Run Forward
0 - None
1 - Enable
2 - Fireman's Override
3 - Speed- A
4 - Speed- B
5 - Setpoint-A
6 - Setpoint-B
7 - Damper LSW
8 - Reserved
9 - External Trip
10 - Reserved
11 - Reserved
12 - 2nd Acc/Dec Time
13 - 3-Wire Start
14 - 3-Wire Stop
15 - HOA Auto
16 - HOA Hand
17 - Shutdown
18- Fault Reset
19- Bypass
20- Reserved
Default: None

DryInput1functionselectionVFDdoesnot
allowmorethanoneDItobesettothesame
selectionexcept(None).(21)isnotforfirst
release

I/O-2: D1-SG Input
D1-SG Input
2) N.O.
0 – Normally Open
1 – Normally Closed
Default: N.O.

DryInput1Contact 

I/O-3: D2-SG Function
D2-SG Function
3) None
0 - None
1 - Enable
2 - Fireman's Override
3 - Speed- A
4 - Speed- B
5 - Setpoint-A
6 - Setpoint-B
7 - Damper LSW
8 - Reserved
9 - External Trip
10 - Reserved
11 - Reserved
12 - 2nd Acc/Dec Time
13 - 3-Wire Start
14 - 3-Wire Stop
15 - HOA Auto
16 - HOA Hand
17 - Shutdown
18- Fault Reset
19- Bypass
20- Reserved
Default: None

DryInput2functionselection.VFDdoesnot
allowmorethanoneDItobesettothesame
selectionexcept(None).(21)Analoginput
switchisnotforfirstrelease

I/O-4: D2-SG Input
D2-SG Input
4) N.O.
0 – Normally Open
1 – Normally Closed
Default: N.O.

DryInput2Contact

I/O-5: V1-
V
2 Function
V1-V2 Function
5) Speed A
0 - None
1 - Enable
2 - Fireman's Override
3 - Speed- A
4 - Speed- B
5 - Setpoint-A
6 - Setpoint-B
7 - Damper LSW
8 - Reserved
9 - External Trip
10 - Reserved
11 - Reserved
12 - 2nd Acc/Dec Time
13 - 3-Wire Start
14 - 3-Wire Stop
15 - HOA Auto
16 - HOA Hand
17 - Shutdown
18- Fault Reset
19- Bypass
20- Reserved
Default: None

Wet Input 1 function selection VFD does not
allow more than one DI to be set to the same
selection except (None).(21) is not for first
release

I/O-6: V1-
V
2 Input
V1-V2 Input
6) Active High
0 - Active High
1 - Active Low
Default: Active High

WetInput1Contact

