Franklin Q-link - Communications Parameter Group

58

7.5 Communications Parameter Group
Code
Modbus
Address
FullParameterName
OLEDDisplay
Name
ParameterSetting
Range

Adj.During
Run
1 501 Protocol Protocol 0‐ModbusRTU
1‐ModbusTCP/IP
2‐BACnetMS/TP
3‐BACnetIP
Yes
3 503 WriteAccess WriteAccess 0‐Disabled
1‐Enabled
Yes
4 504 LossofComms ComLossAction 0–Fault
1–Stop(usesselected
stopmode)
2–HoldSpeed
Yes
5 505 Timeout ComLossDelay 0.1to120.0[Sec] Yes
6 506 Baudrate RS‐485Baud 0‐9600
1‐19200
2‐38400
3‐57600
4‐76800
5‐115200
Yes
7 507 Parity/StopBits ModbusRTU 0‐None,2Stop
1‐Even,1Stop
2‐Odd,1Stop
3–None,1Stop
Yes
9 509 ModbusDeviceAddress ModbusRTU
Address
1‐247 Yes
10 N/A BACnetMAC/ID BACnetMS/TP
MACAddress
0to127 Yes
11 N/A BACnetMaxMaster BACnetMS/TP
MaxMaster
0to127 Yes
12 N/A BACnetDeviceInstance BACnetDevice 0‐4194303 Yes
27 527 CommsRun/Stop N/A 0‐Stop
1‐Run
Yes
28 528 CommsCommandFrequency N/A MinFreqLimittoHigh
FreqLimit
Yes
29 529 CommsPIDSetpoint N/A 0.0to95%of[PID
FeedbackMax]
Yes
30 530 CommsResetFault N/A 0‐None
1‐Reset
Yes
36 536 BluetoothEnable Bluetooth 0‐Disable
1‐Enable
Yes


