8.7 View Information
V
IEW-1: VFD Output Frequency
Output Frequency
1)
Min: 0.0
Max: 240.00 [Hz]

DisplaystheVFDoutputfrequency.

V
IEW-2: Motor Speed
Motor Speed
2)
Min: 0.0
Max: 3600 [RPM]

DisplaysthecurrentRPMofthemotor.

V
IEW-3: Wattmete
r
Wattmeter
3)
Min: 0.0
Max: 4294967 [kWh]

DisplaysthecurrentWattagemeasurement.

V
IEW-5: Average Output Current
Average Current
5)
Min: 0.0
Max: 6x VFD FLA [A]

DisplaystheAverageOutputCurrent.

V
IEW-6: Line U Current
Line U Current
6)
Min: 0.0
Max: 6x VFD FLA [A]

DisplaystheLineUCurrent.

V
IEW-7: Line V Current
Line V Current
7)
Min: 0.0
Max: 6x VFD FLA [A]

DisplaysthelineVCurrent.

V
IEW-8: Line W Current
Line W Current
8)
Min: 0.0
Max: 6x VFD FLA [A]

DisplaystheLineWCurrent.

V
IEW-9: DC Bus Voltage
DC Bus Voltage
9)
Min: 0.0
Max: 1000.0

DisplaystheDCbusvoltage.

V
IEW-10: Output Voltage
Output Voltage
10)
Min: 0.0
Max: 600.0

DisplaystheVFDcalculatedoutputvoltage
(RMS).

V
IEW-11: Output Status
Output Status
11)
0 - VFD Off
1 - Accelerate
2 - Decelerate
3 - Steady
4 - Speed search
5 - Flying start
6 - DC output
7 - Preheat
8 - DC trip prevention
9 - Stall prevention
10 - Bypass off
11 - Bypass run

Displaystheoutputstatus.

V
IEW-12: System Status
System Status
11)
0 - VFD stop
1 - VFD run
2 - VFD disabled
3 - VFD fault
4 - VFD shutdown
5 - VFD fireman's
override
6 - VFD auto reset
8 - Power-on delay
12 - Signal loss
14 - PID run
15 - Open damper
18 - Bypass stop
19 - Bypass manual
20 - Bypass override
22 - Bypass auto on
fault
23 - Bypass disabled
24 - Bypass fault
25 - Bypass shutdown
27 - Bypass auto on
comms loss

Displaysthecurrentsystemoperatingstatus.

