Franklin Q-link - Protection Parameter Group

56


Code
OLEDDisplay
Name
Basic SupplyFan ExhaustFan
Cooling
Tower
Surface/
Booster
Pump
53 O3‐O4‐O5
Function
(0)Fault (0)Fault (0)Fault (0)Fault (0)Fault
64 3AInputMinmA 4.00[mA] 4.00[mA] 4.00[mA] 4.00[mA] 4.00[mA]
65 3AMinHz 0.00[Hz] 0.00[Hz] 0.00[Hz] 0.00[Hz] 0.00[Hz]
66 3AInputMax
mA
20.00[mA] 20.00[mA] 20.00[mA] 20.00[mA] 20.00[mA]
67 3AMaxHz 60.00[Hz] 60.00[Hz] 60.00[Hz] 60.00[Hz] 60.00[Hz]
68 3AInputFilter (0)Low (0)Low (0)Low (0)Low (0)Low
31
 
 
33
 
 
7.4 Protection Parameter Group
Code
Modbus
Address
FullParameterName
OLEDDisplay
Name
ParameterSetting
Range

Adj.During
Run
1 401 Pre‐HeatMode PreheatMode 0‐Disabled
1‐LowHeat
2‐MediumHeat
3‐HighHeat
Yes
3 403 NoMotorTripSelection NoMotorFault 0‐Disable
1‐Enable
No
4 404 StallPrevention StallPrevention 0‐Disable
1‐Enable
No
5 405 StallLevel StallLevel 30to200% No
6 406 DCTripPrevention DCTripPrevent 0‐Disabled
1‐Enabled
No
7 407 MotorOverload(MOL)Level
Continuous
VFDMOL
Continuous
50to135[%] No
8 408 VFDMotorOverload(MOL)
Class
VFDMOL 0‐Class5
1‐Class6(Pump)
2‐Class10
3‐Class20
No
9 409 BypassMotorOverload
(MOL)Class
BypassMOL 0‐Class5
1‐Class6(Pump)
2‐Class10
3‐Class20
No
12 412 MotorOvercurrentLevel OvercurrentLevel 70to200[%] Yes
13 413 MotorOCDelay OvercurrentDelay 0.1to5.0[Sec] Yes
38 438 CriticalFaultsNumberof
AutoRetries
CritFaultRetries 0to10  Yes
