7.3 I/O Terminals Parameter Group
Code
Modbus
Address
FullParameterName
OLEDDisplay
Name
ParameterSetting
Range

Adj.During
Run
1 301 DryInput1Function D1‐SGFunction 0‐None
1‐Enable
2‐Fireman'sOverride
3‐Speed‐A
4‐Speed‐B
5‐Setpoint‐A
6‐Setpoint‐B
7‐DamperLSW
9‐ExternalTrip
10‐RunForward
13‐3‐WireStart
14‐3‐WireStop
15‐HOAAuto
16‐HOAHand
17‐Sh
utdown
18‐FaultReset
19‐Bypass

No
2 302 DryInput1Contact D1‐SGInput 0‐NormallyOpen
1‐NormallyClosed
No
3 303 DryInput2Function D2‐SGFunction 0‐None
1‐Enable
2‐Fireman'sOverride
3‐Speed‐A
4‐Speed‐B
5‐Setpoint‐A
6‐Setpoint‐B
7‐DamperLSW
9‐ExternalTrip
10‐RunForward
13‐3‐WireStart
14‐3‐WireStop
15‐HOAAuto
16‐HOAHand
17‐Sh
utdown
18‐FaultReset
19‐Bypass

No
4 304 DryInput2Contact D2‐SGInput 0‐NormallyOpen
1‐NormallyClosed
No
