7.2 VFD Parameter Group
Code
Modbus
Address
FullParameterName
OLEDDisplay
Name
ParameterSetting
Range

Adj.During
Run
4 204 AutoBypassSelection AutoBypass 0‐Disabled
1‐OnVFDFault
2‐BypassComms
Loss
3‐VFDFault&
BypassCommsLoss
No
6 206 Damper DamperControl 0‐Disabled
1‐Damper*
No
7 207 Damper DamperDelay 0to6000[Sec] Yes
10 210 SkipFrequency1Selection SkipFreq1
Enable
0‐Disabled
1‐Enabled*
No
11 211 SkipFrequency1Low* SkipFreq1Low 0.50to[Skip‐1High
Hz]
Yes
12 212 SkipFrequency1High* SkipFreq1High [Skip‐1LowHz]to
[VFDMaxHz]
Yes
13 213 SkipFrequency2Selection SkipFreq2
Enable
0‐Disabled
1‐Enabled
No
14 214 SkipFrequency2Low* SkipFreq2Low 0.50to[Skip‐2High
Hz]
Yes
15 215 SkipFrequency2High* SkipFreq2High [Skip‐2LowHz]to
[VFDMaxHz]
Yes
16 216 SkipFrequency3Selection SkipFreq3
Enable
0‐Disabled
1‐Enabled
No
17 217 SkipFrequency3Low* SkipFreq3Low 0.50to[Skip‐3High
Hz]
Yes
18 218 SkipFrequency3High* SkipFreq3High [Skip‐3LowHz]to
[VFDMaxHz]
Yes
19 219 PresetFrequency‐A SpeedA VFDLowHzLimitto
VFDMaxHz
Yes
20 220 PresetFrequency‐B SpeedB VFDLowHzLimitto
VFDMaxHz
Yes
21 221 PresetFrequency‐AB SpeedAB VFDLowHzLimitto
VFDMaxHz
Yes
22 222 PresetSetpoint‐A SetpointA 0.00toF/BMax
Value*0.95[Unit]
Yes
23 223 PresetSetpoint‐B SetpointB 0.00toF/BMax
Value*0.95[Unit]
Yes
24 224 PresetSetpoint‐AB SetpointAB 0.00toF/BMax
Value*0.95[Unit]
Yes


