46
Code
OLEDDisplay
Name
Basic SupplyFan ExhaustFan
Cooling
Tower
Surface/
Booster
Pump
23 HandRunCmd 0‐HOAin
Hand
0‐HOAin
Hand
0‐HOAin
Hand
0‐HOAin
Hand
0‐HOAin
Hand
24 HandSpeedRef 0‐Keypad 0‐Keypad 0‐Keypad 0‐Keypad 0‐Keypad
30 StopMode 1(Coast) 1(Coast) 1(Coast) 1(Coast) 1(Coast)
31 StopMode 10[Hz] 10[Hz] 10[Hz] 10[Hz] 10[Hz]
32 DCBrakingStart
Frequency
50[%] 50[%] 50[%] 50[%] 50[%]
33 DCBraking
Current
5.0[sec] 5.0[sec] 5.0[sec] 5.0[sec] 5.0[sec]
34 Acceleration
Time
30.0[sec] 30.0[sec] 30.0[sec] 30.0[sec] 20.0[sec]
35 Deceleration
Time
40.0[sec] 40.0[sec] 40.0[sec] 40.0[sec] 30.0[sec]
36 V/FControl 0(Linear) 1(Squared) 1(Squared) 1(Squared) 0(Linear)
39 Speed‐Search
VoltageGain
100% 100% 100% 100% 100%
40 Speed‐Search
SpeedOffset
5.0[Hz] 5.0[Hz] 5.0[Hz] 5.0[Hz] 5.0[Hz]
41 AutoRunCmd (1)Terminal (1)Terminal (1)Terminal (1)Terminal (1)Terminal
42 AutoSpeedRef (1)1AInput (4)PID (4)PID (4)PID (4)PID
43 AnlgRefLoss (0)Disabled (1)Halfof
Min
(1)Halfof
Min
(1)Halfof
Min
(1)Halfof
Min
44 AnlgRefLoss
Act
(0)Fault (1)Stop (1)Stop (2)Hold (1)Stop
45 AnlgRefLoss 1[Sec] 1[Sec] 1[Sec] 1[Sec] 1[Sec]
46 PIDMode (0)Direct (0)Direct (1)Inverse (1)Inverse (0)Direct
47 SetpointSource (0)Keypad (0)Keypad (0)Keypad (0)Keypad (0)Keypad
48 Feedback
Source
(0)1AInput (0)1AInput (0)1AInput (0)1AInput (0)1AInput
49 FeedbackUnits (0)PSI (2)inWC (2)inWC (6)°F (0)PSI
50 FeedbackMax 100.00[PSI] 10.00[inWC] 10.00[inWC] 150.00[°F] 100.00[PSI]
52 KeypadSetpoint 60.00[PSI] 1.00[inWC] 1.00[inWC] 78.00[°F] 60.00[PSI]
55 PGain 30[%] 10[%] 10[%] 10[%] 30[%]
56 IGain 1.0[sec] 1.0[sec] 1.0[sec] 1.0[sec] 0.5[sec]
57 PIDRampTime 0.0[sec] 0.0[sec] 0.0[sec] 0.0[sec] 0.0[sec]
58 PIDHighFreq
Limit
60.00[Hz] 60.00[Hz] 60.00[Hz] 60.00[Hz] 60.00[Hz]
59 PIDLowFreq
Limit
20.00[Hz] 15.00[Hz] 15.00[Hz] 15.00[Hz] 20.00[Hz]
60 FdbkLoss (1)Halfof
Min
(1)Halfof
Min
(1)Halfof
Min
(1)Halfof
Min
(1)Halfof
Min
61 FdbkLoss
Action
(1)Stop (1)Stop (1)Stop (2)Hold (1)Stop
62 FdbkLossDelay 1[Sec] 1[Sec] 1[Sec] 1[Sec] 1[Sec]
