Franklin Q-link - Page 45

45

Code
Modbus
Address
FullParameterName
OLEDDisplay
Name
ParameterSettingRange

Adj.During
Run
61 161 FeedbackLossAction FdbkLossAction 0‐Fault
1‐Stop(usesselected
stopmode)
2‐HoldSpeed
No
62 162 FeedbackLossDelay FdbkLossDelay 0to10[Sec] No

PrimaryGroupApplicationDefaults
Code
OLEDDisplay
Name
Basic SupplyFan ExhaustFan
Cooling
Tower
Surface/
Booster
Pump
2 MotorVoltage 200V/575V 200V/575V 200V/575V 200V/575V 200V/575V
3 Motor
Horsepower
ByVFD
Rating&
LineVoltage
ByVFD
Rating&
LineVoltage
ByVFD
Rating&
LineVoltage
ByVFD
Rating&
LineVoltage
ByVFD
Rating&
LineVoltage
4 MotorCurrent ByULTable
byLineHz&
Voltageand
VFDRating
ByULTable
byLineHz&
Voltageand
VFDRating
ByULTable
byLineHz&
Voltageand
VFDRating
ByULTable
byLineHz&
Voltageand
VFDRating
ByULTable
byLineHz&
Voltageand
VFDRati
ng
5 MotorRPM 1750[RPM] 1750[RPM] 1750[RPM] 1750[RPM] 1750[RPM]
6 LineFrequency 1‐60[Hz] 1‐60[Hz] 1‐60[Hz] 1‐60[Hz] 1‐60[Hz]
7 MaxFrequency 60.00[Hz] 60.00[Hz] 60.00[Hz] 60.00[Hz] 60.00[Hz]
8 BaseFrequency 60.00[Hz] 60.00[Hz] 60.00[Hz] 60.00[Hz] 60.00[Hz]
9 HighFrequency
Limit
60.00[Hz] 60.00[Hz] 60.00[Hz] 60.00[Hz] 60.00[Hz]
10 LowFrequency
Limit
15.00[Hz] 15.00[Hz] 15.00[Hz] 15.00[Hz] 20.00[Hz]
11 Carrier
Frequency
2.5[kHz] 2.5[kHz] 2.5[kHz] 2.5[kHz] 2.5[kHz]
15 Power‐OnRun 1‐Enable 1‐Enable 1‐Enable 1‐Enable 1‐Enable
16 Power‐OnRun
Delay
5[Sec] 5[Sec] 5[Sec] 5[Sec] 5[Sec] 
17 FaultReset&
Run
1‐Enable 1‐Enable  1‐Enable 1‐Enable 1‐Enable
18 TorqueBoost 0‐Disable 0‐Disable 0‐Disable 0‐Disable 0‐Disable
19 TorqueBoost
Level
2.00 2.00 2.00 2.00 2.00
20 StartMode 2‐Flying
start
2‐Flying
start
2‐Flying
start
2‐Flying
start
0‐Accel
21 DCStartLevel 0‐Low 1‐Medium 1‐Medium 1‐Medium 0‐Low
22 HOAType 0‐Keypad
HOA
0‐Keypad
HOA
0‐Keypad
HOA
0‐Keypad
HOA
0‐Keypad
HOA

