91

V
IEW-51: O3-O4 Output
2A Type
51)
0 - Open
1 - Closed
Displays status of Relay Output 2 (N.C., form C).
V
IEW-52: O4-O5 Output
2A Type
52)
0 - Open
1 - Closed
Displays the status of Relay Output 2 (N.O., form C).
V
IEW-53: 3A mA Input
3A Input
53)
Read Only
Analog Input in mA.
V
IEW-100: Bluetooth Key
Bluetooth Key
100)
Default: XXXXXXXX
V
IEW-116: Bluetooth MAC ID
Bluetooth MAC ID
116)
Default: XXXXXXXXX
V
IEW-128: Bluetooth Name
Bluetooth Name
128)
Default: XXXXXXXXX
The Bluetooth name is the name that is being
broadcast by the device. It is a portion of the
Bluetooth key and is represented in base 36.
8.8 Fault Codes
FAULT-1: Fault
Fault
1)
0 - None
1 - Motor Overload (C)
2 - Motor Over Current
(C)
4 - VFD Over Heat (C)
8 - Input Phase Open
(L)
9 - Output Phase Open
(L)
10 - No Motor (L)
11 - Incorrect Output
Wiring
12 - Power Board
Uncalibrated
13 - Ground Fault (L)
21 - Bypass Motor
Overload (L)
26 - Bypass Max Time
(L)
27 - Bypass Ground
Fault (L)
28 - Bypass
Communications Error
29 - Bypass Contactor
(L)
30 - Bypass Current at
Power On (L)
31 - Bypass No Motor
Current (L)
33 - Bypass
Unexpected Current (L)
41 - Limit Switch
42 - Damper Overload
(L)
43 - Control Reserved
44 - No Flow (L)
45 - External Trip (M)
47 - Control Board Error
(M)
48 - VFD Cooling Fan
(L)
50 - Overpressure (A)
51 - BMS
Communications Loss
(A)
52 - Analog Signal Loss
53 - Transducer Signal
Loss (A)
54 - EEPROM Fail
55 - Calibration CRC
Failed
56 - Bluetooth Key CRC
Failed

Displaysthefaulttype.

(C)‐Criticaltypefaultsrequirelongretrydelay
(L)‐Lighttypefaultsallowshortretrydelay
(M)‐FaultsrequireReset4
(A)‐FaultswithAutoReset/Restartabilities

AttheendofProtectiongroupthereare
separateretryparametersfor(C)Criticaland(L)
Lightfaults 

FAULT-4: Line U Current
Line U Current
4)
Min: 0.0
Max: 6x VFD FLA (A)

DisplaysthephaseAoutputcurrentatthetime
ofthefault.DisplayeduponVFDfault.

