FAULT-5: Line
V
Current
Line V Current
5)
Min: 0.0
Max: 6x VFD FLA (A)

DisplaysthephaseBoutputcurrentatthetime
ofthefault.DisplayeduponVFDfault.

FAULT-6: Line W Current
Line W Current
6)
Min: 0.0
Max: 6x VFD FLA (A)

DisplaysthephaseCoutputcurrentatthetime
ofthefault.DisplayeduponVFDfault.

FAULT-7: DC Bus Voltage 1
DC Bus Voltage 1
7)
Min: 0.0
Max: 1000 (V)

DisplaystheDCbusvoltageattimeofthe
fault.DisplayedandsaveduponVFDfault.

FAULT-8: DC Bus Voltage 2
DC Bus Voltage 2
8)
Min: 0.0
Max: 1000 (V)

DisplaystheDCbusvoltagecaptured100ms
afterthefault.

FAULT-9: Target Frequency
Target Frequency
9)
Min: 0.0
Max: 240.00 (Hz)

Displaysthetargetfrequencyatthetimeofthe
fault.DisplayeduponVFDfault.

FAULT-10: Output Frequency
Output Frequency
10)
Min: 0.0
Max: 240.00 (Hz)

Displaystheoutputfrequencyatthetimeofthe
fault.DisplayeduponVFDfault.

FAULT-12: System Status
System Status
12)
0 - VFD stop
1 - VFD run
2 - VFD disabled
3 - VFD fault
4 - VFD shutdown
5 - VFD fireman's
override
6 - VFD auto reset
8 - Power-on delay
12 - Signal loss
14 - PID run
15 - Open damper
18 - Bypass stop
19 - Bypass manual
20 - Bypass override
22 - Bypass auto on
fault
23 - Bypass disabled
24 - Bypass fault
25 - Bypass shutdown
27 - Bypass auto on
comms loss

Displaystheoperatingmodeatthetimeofthe
fault.DisplayeduponVFDfault.

FAULT-11: Output Status
Output Status
11)
0 - VFD Off
1 - Accelerate
2 - Decelerate
3 - Steady
4 - Speed search
5 - Flying start
6 - DC brake
7 - Preheat
8 - DC trip prevention
9 - Stall prevention
10 - Bypass off
11 - Bypass run

Displaysthesystemoutputatthetimeofthe
fault.

FAULT-13: HOA Mode
HOA Mode
13)
0 - Hand
1 - Off
2 - Auto
3 - Bluetooth

DisplaysstatusoftheHOAswitchattimeofthe
fault.DisplayeduponVFDorBypassfault.

