90
IEW-21: Motor Run Time
Motor Run Time
21)
Min: 0
Max: 4294967295
IEW-23: D1-SG Input
D1-SG Input
23)
0 - Open
1 - Closed
Displays status of Digital Input 1.
IEW-24: D2-SG Input
D2-SG Input
24)
0 - Open
1 - Closed
Displays status of Digital Input 2.
IEW-25: V1-
2 Input
V1-V2 Input
25)
0 - Deenergized
1 - Energized
Displays status of Voltage Input 1.
IEW-26:
3-
4 Input
V3-V4 Input
26)
0 - Deenergized
1 - Energized
Displays status of Voltage Input 2.
IEW-27: O1-O2 Output
O1-O2 Output
27)
0 - Open
1 - Closed
Displays status of Output Relay 1.
IEW-28: HOA Status
HOA Mode
28)
0 - Off
1 - Hand
2 - Auto
3 - Bluetooth
Displays status of HOA selector.
IEW-32: 1A Input Voltage
1A Input
32)
Min: 0.00
Max: 24.00
IEW-34: 2A V Input
2A V Input
34)
Min: 0.00
Max: 10.00
t
IEW-37: Powe
Average Power
37)
Varies depending
on VFD size [kW]
IEW-39: Target Frequency
Target Frequency
39)
Min: PRIMARY-10
Max: PRIMARY-9
IEW-40: Run Command Source
Run Command
40)
0 - None
1 - Run
2 -Terminals
3 - 3 Wire
4 - Communication
5 - Mobile
IEW-41: Speed Reference Source
Speed Reference
41)
0 - None
1 - Keypad
2 - Analog 1A
3 - Analog 2A
4 - Communication
5 - Mobile
6 - PID
IEW-46: VFD Cooling Fan RPM
Cooling Fan
46)
Min: 0
Max: 7200 [RPM]
IEW-47: 1A Type
N/A
47)
0 – 0-10V Input
1 – 4-20mA Input
States the current hardware configuration of the 1A
Analog Input (DIP switch selection)
IEW-48: 2A Type
N/A
48)
0 – 0-10V Input
1 – 0-10V Output
2 – 4-20mA Output
States the current hardware configuration of the 2A
Analog Input/Output (DIP switch selection)
IEW-49: D3-SG Input
2A Type
49)
0 - Open
1 - Closed
Displays status of Digital Input 3.
IEW-50: D4-SG Input
2A Type
50)
0 - Open
1 - Closed
Displays status of Digital Input 4.
