89


V
IEW-13: Fault
HOA Mode
13)
0 - None
1 - Motor Overload (C)
2 - Motor Over Current
(C)
3 - VFD Over Current (C)
4 - VFD Over Heat (C)
5 - VFD Short Circuit (C)
6 - Over Voltage (L)
7 - Under Voltage (L)
8 - Input Phase Open (L)
9 - Output Phase Open
(L)
10 - No Motor (L)
11 - Incorrect Output
Wiring
12 - Power Board
Uncalibrated
13 - Ground Fault (L)
21 - Bypass Motor
Overload
22 - Bypass Phase
Unbalance
23 - Bypass Phase Loss
24 - Bypass Board Error
25 - Bypass Stall
26 - Bypass Max Time
27 - Bypass Ground
Fault
28 - Bypass
Communications Error
29 - Bypass Contactor
30 - Bypass Current At
Power On
31 - Bypass No Motor
Current
32 - Bypass Locked
Rotor
33 - Bypass Unexpected
Current
34 - Bypass No Motor
Current
41 - Limit Switch (H)
42 - Damper Overload
(L)
43 - Control Reserved
44 - No Flow (L)
45 - External Trip (M)
46 - Power Board Error
(M)
47 - Control Board Error
(M)
48 - VFD Cooling Fan (L)
49 - Power Board
Communications Error
(M)
50 - Overpressure (A)
(P)
51 - BMS
Communications Loss
(A)
52 - Analog Signal Loss
53 - Transducer Signal
Loss (A)
54 - EEPROM Error
55 - Calibration CRC
Failed
56 - Bluetooth Key CRC
Failed
57 - Invalid Firmware

Displaysthefaulttype.

(C)‐Criticaltypefaultsrequirelongretrydelay
(L)‐Lighttypefaultsallowshortretrydelay
(M)‐Faultsrequiremanualreset
(A)‐FaultswithAutoReset/Restartabilities

AttheendofProtectiongroupthereare
separateretryparametersfor(C)Criticaland(L)
Lightfaults.
V
IEW-15: PID Feedback Value
PID Feedback Value
15)
Min: 0
Max: 3000
Displays the current PID feedback value in selected
units. (PSI, GPM, etc.)
V
IEW-16: 2
nd
Input Value (Units)
2
nd
Input Value
16)
Min: 0
Max: 3000
Analog input in selected units (decimals depend on
selected unit)
V
IEW-17: Inverte
r
Temperature
IGBT Temp
17)
Min: 0.0
Max: 160.0
Displays the current IGBT temperature in degrees C,
and as percentage of IGBT temp rating.
V
IEW-18: Ambient Temperature
Ambient Temp
18)
Min: 0.0
Max: 160.0
V
IEW-19: Powe
r
-On Time
Power-On Time
19)
Min: 0
Max: 4294967295
Displays the system time most significant digits:
YY/MM/DD/HH/MM
