I/O-7: V3-
V
4 Function
V3-V4 Function
7) External Trip
0 - None
1 - Enable
2 - Fireman's Override
3 - Speed- A
4 - Speed- B
5 - Setpoint-A
6 - Setpoint-B
7 - Damper LSW
8 - Reserved
9 - External Trip
10 - Reserved
11 - Reserved
12 - 2nd Acc/Dec Time
13 - 3-Wire Start
14 - 3-Wire Stop
15 - HOA Auto
16 - HOA Hand
17 - Shutdown
18- Fault Reset
19- Bypass
20- Reserved
Default: None

WetInput2functionselectionVFDdoesnot
allowmorethanoneDItobesettothesame
selectionexcept(None).

I/O-8: V3-
V
4 Input
V3-V4 Input
8) Active High
0 - Active High
1 - Active Low
Default: Active High

WetInput2Contact

I/O-9: O1-O2 Function
01-02 Function
9) Fault
0 - Fault
1 - Run
2 - Proof of Run
Default: Fault

RelayOutputDefinition

I/O-10: O1-O2 Output Contact
01-02 Output
10) N.O.
0 – Normally Open
1 – Normally Closed
Default: N.O.

RelayOutputContact

I/O-14: 1A Input Min m
A
1A Input Min mA
14) 4mA
Min: 0.00mA
Max: 20.00mA
Default: 4.00mA

1AmAInputminimumvalue.

I/O-15: 1A Input Min Hz
1A Min Hz
15) 0Hz
Min: 0.00 Hz
Max: PRIMARY-7
Default: 0.00 Hz

1AVnoisefiltering:0=100ms,1=250ms,
2=500ms

I/O-16: 1A Input Max mA
1A Input Max mA
16) 20mA
Min: 0.00mA
Max: 20.00mA
Default: 20.00mA

1AmAorVInputfrequencycorrespondingto
Maxvalue

I/O-17: 1A Input Max Hz
1A Input Max Hz
17) 60Hz
Min: 0.00 Hz
Max: PRIMARY-7
Default: 60.00 Hz

1AVoltageInputminimumvalue.For2‐10VDC
signalsetitto2V

I/O-18: 1A Input Filtering Level
1A Input Filter
19) Low
0 - Low
1 - Medium
2 – High
Default: Low

I/O-19: 1A Input Min
V
1A Input Min V
19) 0V
Min: 0.0V
Max: 10.0V
Default: 0.0V

1AmAInputminimumvalue.For4‐20mAsignal 
setitto4mA

I/O-21: 2A Input Filte
r
2A Input Filter
21) 0.0V
Min: 0.0V
Max: 10.0V
Default: 0.0V

I/O-23: 2A Input Filte
r
2A Input Filter
23) Medium
0 - Low
1 - Medium
2 – High
Default: Medium

2AVnoisefiltering:0=100ms,1=250ms,
2=500ms

