Franklin Q-link - Page 82

82


I/O-24: 2A Input Min
V
2A Input Min V
24) 0V
Min: 0.0V
Max: 10.0V
Default: 0.0V

2AVoltageInputminimumvalue.For2‐10VDC
signalsetitto2V

I/O-25: 2A Input Min Hz
2A Input Min Hz
25) 0Hz
Min: 0.00 Hz
Max: PRIMARY-7
Default: 0.00 Hz

2AVoltageInputmaximumvalue. For0‐5VDC
signalsetitto5V

I/O-26: 2A Input Max V
2A Input Max V
26) 10V
Min: 0.0V
Max: 10.0V
Default: 10.0V

2AVoltageInputfrequencycorrespondingtoV
Min

I/O-27: 2A Input Max Hz
2A Input Max Hz
27) 60Hz
Min: 0.00
Max: PRIMARY-7
Default: 60.00 Hz

2AVoltageInputfrequencycorrespondingtoV
Max

I/O-28: 2A Output Function
2A Function
28) Output Frequency
Default: Out. Freq.
0 - Output Frequency
1 - Output Current
2 - DC Bus Voltage
3 - Repeat 1A*
4- Repeat 3A*

2AAnalog Output(0‐10V or4‐20mAset by DIP
Switch) parameter  selection. Analog output is
scaled to Max value of the  selected
parameter.Example: DC Link Voltage is 0‐
1000VDC. 

I/O-29: 2A Output Scaling
2A Output Scaling
29) 100%
Min: 10%
Max: 200%
Default: 100%

2A Analog output scaling. For max Frequency
60Hzat50%setting,2Aoutputwillprovide5VDC
or12mA(dependingon2ADIPSwposition).

I/O-48: Option Board Enable
Option Board
48) Enabled
0 - Disable
1 – Enable
Default: Enabled

I/O-49: Dry Input 3 Function
D3-SG Function
49) None
0 - None
1 - Enable
2 - Fireman's Override
3 - Speed- A
4 - Speed- B
5 - Setpoint-A
6 - Setpoint-B
7 - Damper LSW (H)
8 - Reserved
9 - External Trip
10 - Reserved
11 - Reserved
12 - 2nd Acc/Dec Time
13 - 3-Wire Start
14 - 3-Wire Stop
15 - HOA Auto
16 - HOA Hand
17 - Shutdown
18- Fault Reset
19- Bypass
20- Reserved
Default: None

I/O-50: Dry Input 3 Contact
D3-SG Input
50) N.O.
0 – Normally Open
1 – Normally Closed
Default: N.O.

I/O-51: Dry Input 3 Contact
D3-SG Function
51) None
0 - None
1 - Enable
2 - Fireman's Override
3 - Speed- A
4 - Speed- B
5 - Setpoint-A
6 - Setpoint-B
7 - Damper LSW (H)
8 - Reserved
9 - External Trip
10 - Reserved
11 - Reserved
12 - 2nd Acc/Dec Time
13 - 3-Wire Start
14 - 3-Wire Stop
15 - HOA Auto
16 - HOA Hand
17 - Shutdown
18- Fault Reset
19- Bypass
20- Reserved
Default: None
