I/O-52: Dry Input 4 Contact
D4-SG Input
52) N.O.
0 – Normally Open
1 – Normally Closed
Default: N.O.

I/O-53: Relay 3 Output Select
O3-O4-O5 Function
53) Fault
0 - Fault
1 - Run
2 - Proof of Run
Default: (0) Fault

2AVoltageInputminimumvalue.For2‐10VDC
signalsetitto2V

I/O-64: 3A mA Min Value
3A Input Min mA
64) 0Hz
Min: 0.00
Max: 20.00 [mA]
Default: 0.00

2AVoltageInputmaximumvalue. For0‐5VDC
signalsetitto5V

I/O-65: 3A Min Hz
3A Min Hz
65) 0Hz
Min: 0.00
Max: PRIMARY-7
Default: 0.00

2AVoltageInputfrequencycorrespondingtoV
Min

I/O-66: 3A mA Max Value
3A mA Max Value 
66) 20.00mA
Min: 0.00
Max: 20.00 [mA]
Default: 20.00 [mA]

2AVoltageInputfrequencycorrespondingtoV
Max

I/O-67: 3A Max Hz
3A Max Hz
67) 60Hz
Min: 0.00
Max: PRIMARY-7
Default: 60.00 Hz

2AAnalog Output(0‐10V or4‐20mAset by DIP
Switch) parameter  selection. Analog output is
scaled to Max value of the  selected
parameter.Example: DC Link Voltage is 0‐
1000VDC. 

I/O-68: 3A Input Filtering Level
3A Input Filter
68) Fault
0 - Fault
1 - Run
2 - Proof of Run
Default: (0) Fault

2A Analog output scaling. For max Frequency
60Hzat50%setting,2Aoutputwillprovide5VDC
or12mA(dependingon2ADIPSwposition).

