PRIMARY-5: Rated Motor RPM
Motor RPM
5) 1750RPM
Min: 500
Max: 3600
Default: 1750
MotorRPMcanbechangedtomotor
nameplateRPMifdifferentfromdefault.Itis
usedformotorspeeddisplayproperscaling.
PRIMARY-6: Power Line Frequency
Line Frequency
6) 60Hz
0 - 50Hz
1 - 60Hz
Default: 60Hz
Power Line Standard Frequency(for VFD and
Bypass)‐TheLineFrequency parametershould
besetto matchthepowerline frequency 50Hz
or60Hz.
PRIMARY-7: Maximum Frequency
Max Frequency
7) 60Hz
Min: 30.00
Max: 240.00
Default: 60.00
ThePRIMARY‐7parametershouldbesettothe
maximum output frequency that VFD can
produceatfullspeedreferencesignal.Formost
standard industrial motors, it should be set to
50Hzor60Hz.
Max Frequency determines the full range of
the VFDspeed control (VFD outputfrequency).
The analog inpu
t range is scaled to VFD
maximumfrequency.
PRIMARY-8: Base Frequency
Base Frequency
8) 60Hz
Min: 30.00
Max: PRIMARY-7
Default: 60.00
VFD provides full output voltage at this
frequency.ThePRIMARY‐8parametershouldbe
settothemotornameplatefrequencyrating.If
MaximumFrequencyissetto70Hz,Baseto60Hz
and Motor Voltage to 230V, the VFD during
accelerationwilloutput230Vat60Hzandfrom
thispointincreaseonlyfre
quencyto70Hz.
PRIMARY-9: High Frequency Limit
High Frequency Limit
9) 60Hz
Min: PRIMARY-10
Max: PRIMARY-7
Default: 60.00
Ifspeed controlsignalexceeds“FrequencyHigh
Limit,”thentheVFDwillrunatFreq.HighLimit
Hz. (PID mode has separate frequency limit
parameters).
TheVFDhasHighandLowlimitsettingsforthe
output frequency in both Remote and Local
control modes. The PID control mode has
separateou
tputfrequency limitsettings. When
VFDspeedreferenceissetbelowLowFrequency
limitoraboveHighlimit,theVFDoutputwillstay
atfrequencylimit.
PRIMARY-10: Low Frequency Limit
Low Frequency Limit
10) 15Hz
Min: 5.00Hz
Max: High Frequency
Default: 15.00
VFD output frequency low limit (No PID).
Low Frequency Limit will be set to 15.00Hz or
20.00Hz based on PRIMARY‐01 selected
application.Ifspeed controlsignal dropsbelow
Frequency Low Limit,VFD willrun at Freq.Low
LimitHz.(PIDmodehasseparatefreque ncylimit
parameters). Example of VFD actual re
ference
with100HzMax.Freq:80HzHighLimitand30Hz
LowLimit.
