PRIMARY-22: HOA Type
HOA Type
22) Keyboard HOA
0 - Keypad HOA
1 - Auto Only
2 - Keypad Off/Auto
3 - External HOA
Default: (0) Keypad HOA
0‐VFDHOA:FullyfunctionalHOAkeypad.
1‐AutoOnly‐HOAisDisabled&VFDisalwaysin
Automode,nochangesbyHOAkeys.
2‐Hand Disabled‐ Fully f unctional Auto Mode
andVFD canbestoppedbyHOAinOFF.NoHand
Mode.
3‐IfExternalHOAisselected,twodi
gitalinputs
shouldbesettoHand andAutoandHOAswitch
should be wire to those inputs. (Ifboth DIs are
activated= Hand).Refer to Fig. 04 and Fig. 05
below.
PRIMARY-23: Run Command in Hand
Hand Run Cmd
23) Always Run
0 - HOA in Hand
1 - Terminal
2 - 3-Wire
3 - Comms
Default: (0) HOA in
Hand
SelectionsforRunCommandin HOAHand
position.VFDstartswhen:
0‐HOAisinHand;
1‐HOA=Handandselectedterminalis
activated;
2‐HOA=Hand&StartButtonispressed,
6 ‐HOA=Hand&startcomm andisgivenvia
comms.
PRIMARY-24: Speed Reference in Hand
Hand Speed Ref
24) Keypad
0 - Keypad
1 - 1A Analog Input
2 - 2A Analog Input
3 - Communications
4 - 3A Analog Input
Default: (0) Keypad
Selections for Speed Reference in HOA Hand
position.
When HOA is in Hand position, PID mode is
disabled. 2A is available when 2A DIP Switch is
settoInput.
PRIMARY-27: Keypad Frequency
Keypad Frequency
27) 15Hz
Min: PRIMARY-10 (Low
Frequency)
Max: PRIMARY-9 (High
Frequency)
Default: 15Hz
FreqreferenceviakeypadinHandorAuto
Mode.
PRIMARY-30: Stop Mode
Stop Mode
30) Coast
Default: Decelerate
0 - Decel
1 - Coast
When stop command is received,VFD will stop
based on selection: DECEL‐Decrease output
frequencyto0HzperDecelerationTimesetting,
COAST‐immediatelystopswitchandmotorwill
coasttoastop
