PRIMARY-42: Speed Reference in Auto
Auto Speed Ref
42) Keypad
0 - Keypad
1 - 1A Analog Input
2 - 2A Analog Input
3 - Comms
4 - PID
5 - 3A Analog Inputs
Default: (0) Keypad
Selection for speed reference source in Auto
mode.1Ainput0‐10VDCor4‐20mAtypewill be
set by 1ADIP switch.2A input isalways 0‐10V.
2Aselectionisavailablewhen2ADIPSwissetto
Input.WhensettoPID,allPIDparameterswillbe
available.
Keypad
WhenVFDHOAAutokeyispressedorexternal
HOASWisputinAutoposition,VFDwillprovide
output frequency corresponding toa reference
givenviaVFDkeypad.
1AInput
Providesfrequencyreferencevia1AInputsetby
DIP Sw to 4‐20mA or 0‐10VDC (scalable in I/O
group).IfDIPSwisin24Vposit
ion,processorstill
treatsitas0‐10VDCbecauseitwillbescaledto
thatlevelbyhardwarecomponents.
2AInput
Providesfrequencyreferencevia2AInputsetby
DIPSwto0‐10VDCinput(scalableinI/Ogroup).
3AInput
Providesfrequencyreferencevia3AInp
utsetby.
Communications
When Communication is selected as a speed
reference source, VFD will provide output
frequency based on reference set by
communications.
PID
VFD speed reference will be provided by PID
control based on difference between PID Set‐
pointandFeedbackvalues.WhensettoPID,all
PID parameters will be available. Wh
en PID
mode is enabled, DC trip prevention, stall
preventionandskipfrequenciesaredisabled.
PRIMARY-43: Reference Loss Condition
Anlg Ref Loss
43) Half of Min
0 - Disabled
1 – Below ½ of Min
2 – Below Min
Default: (1) Half of Min
Select either below minimum value, or below
half of minimum value of the analog signal
selectedasaspeedreferencelosscondition.
PRIMARY-44: Reference Loss Action
Anlg Ref Loss Act
44) Stop
0 - Fault
1 - Stop
2 - Hold Speed
Default: (1) Stop
SelectaVFDactionatsignalloss:
0‐Fault=VFDtripsandmanualresetor
rebootingisrequired;
1‐Stop=VFDstopsusingthestopmode
definedinBASIC30;Providesautorestartwhen
signalvalueisequalorgreaterthanReference
Minvalue,andruncommandispresent.
2‐Hold=VFDrunsatprevi
ousspeed.
