Franklin Q-link - Page 76

76


PRIMARY-57: Out Ramp Time
PID Ramp Time
57)
Min: 0.0
Max: 10.0
Default: 0.0s

SetsPIDoutputramp‐up.Ramp‐downtimewill
besetto150%ofPRIMARY‐57.Extraramptime
inadditiontocalculatedPIDvalue.

PRIMARY-58: PID High Frequency Limit
PID High Freq
58)
Min: Prime-59
Max: Prime-07
Default: 60Hz

PIDfrequencyoutputwillbelimitedbyPrimary‐
58value.

PRIMARY-59: PID Low Frequency Limit
PID Low Freq
59)
Min: 0.0
Max: Prime-58
Default: 20Hz

PIDfrequencyoutputwillbelimitedbyPrimary‐
59value.

PRIMARY-60: Feedback Signal Loss
Fdbk Loss
60) Below ½ Min
0 - Disabled
1 - Below ½ of Min.
2 - Below Min.
Default: Below ½ Min

SignallossconditioneitherHalfofAnalogSignal
minimumvalueorbelowminimumvalue.

PRIMARY-61: Feedback Loss Action
Feedback Loss Action
61) Stop
0 - Fault
1 - Stop
2 - Hold Speed
Default: (1) Stop

SelectaVFDactionatsignalloss:

0‐Faults=VFDfaulttripsandManualresetor
rebootingisrequired;
1‐Stop=VFDstopsusingthestopmode
definedinBASIC30;
2‐Hold=VFDrunsatprevious speed.

1and2selectionsprovideautorestartwhen
F/Bsignalisre
storedanditsvalueisequalor
greaterthanF/BMinvalueandruncommandis
present.


PRIMARY-62: Feedback Loss Delay
Fdbk Loss Delay
62) 1s
Min: 0s
Max: 10s
Default: 1s

Low reading on a sensor could be normal
condition for some period of time. The delay
shouldbesettopreventthedrivefromtripping
undernormalconditions.

