49
Chapter 2
Robot Assemb
ly
█
www.freeno
ve.com
4.
Mount one left an
d one ri
ght legs to the
rear boar
d with b
lack screws
in the ser
vo pack
age.
Assemble them
as close
to 90 deg
rees as po
ssible. An
gles at 70
–
110
degrees are
acceptable.
Left leg
Right
leg
9
0
degrees
9
0
degrees
Head
50
52
