A warning chime and alert message to warn
the driver if the door is opened without first set-
ting the parking brake.
•
A flashing alert message that appears on the
driver message center in low engine oil pres-
sure or high coolant temperature conditions.
With the parking brake released, only the odometer
and alert screens can be displayed. Park the vehicle
and set the parking brake to display additional
screens.
The dash message center displays alert screens
when certain conditions occur. They are warnings,
cautions, or other messages that require the driver’s
attention, but not all of them are critical to the opera-
tion of the vehicle. Warning messages always display
at full brightness.
More important messages take priority over less im-
portant messages. The order of priority, is:
1.
parking brake set (with the vehicle moving)
2.
parking brake off (with door open)
3.
low oil pressure or high coolant temperature
4.
hard brake warnings (if equipped with roll stabil-
ity advisor)
5.
low battery voltage
f040802
From Temp Alert Screen
Press & Hold
Tap
Press & Hold
Tap
Press & Hold
Tap
n = Number of
Active Fault Codes
dlAG
n
*FAULT
01
*If fault goes inactive,
display "noFault 1"
*FAULT
nn
*If fault goes inactive,
display "noFault n"
To Setup Screen (or Oil
Level Screen, if equipped)
Press & Hold
AbS 11 ECU 0
Tap Tap
Press & Hold
123456
Tap Tap
Press & Hold
FAIL 03 FAIL 00
Tap Tap
SPN SPN
123456
01/31/2012
Fig. 4.8, ICU4 Diagnostic and Engine Display Screens
