NOTE: If the vehicle has gone past the service
interval, the miles(km)/hours remaining screen
is replaced by the service was due screen, fol-
lowed by the number of miles(km)/hours since
the service was due.
Setup Information
See Fig. 4.16 for a diagram of the setup information
screens.
Setup information allows you to program various fea-
tures of the ICU4M environment, including:
f040761a
Screen G
FASTEN SEATBELTS
123456.7
MILES
Screen H
IDLE HOURS
1234 : 56
12.3 GAL 123456.7
MI
Screen I
(Note 1)
−
0% ||||||||
+
12.3 mpg 123456.7 mi
RPM >= 100 &&
Park Brake On
RPM < 100
Park Brake OFF
&& RPM >= 100
RPM
<
100
Park Brake Off &&
RPM
>=
100
Park Brake On
Park Brake On
Stationary
Access Screens
NOTE 1
The bar graph portion of this
screen and the Target Fuel Economy
value are only shown when
Target MPG Screen Enable == ON
OUTSIDE AIR
TEMPERATURE −−F
−
VEHICLE
INFORMATION
SETUP
INFORMATION
−
+
+
Park brake on
From SERVICE
INFORMATION
See: SETUP INFORMATION
Screens
Park Brake ON
&& RPM >= 100
−
+
See: VEHICLE INFORMATION
Screens
= My Info
09/10/2009
+
+
Fig. 4.14, ICU4M, Standard Screens
Instruments
4.19
