Error flowchart
Safety
General The error search tree is used to systematically locate and rectify errors.
Before starting any troubleshooting activities, read the "Function overview" section in order
to understand the layout of the device and how it works.
Overview The "Error search tree" section is divided into the following sections:
- LEDs on the primary power module
- LED error search tree
- Electrolyte circulation pump error search tree
WARNING! An electric shock can be fatal. Before opening the device:
- Unplug the device from the mains
- Using a suitable measuring instrument, ensure that electrically charged parts
(e.g. capacitors) are fully discharged
- Restrict access to the working area
- Take steps to ensure the metallic surfaces of the device cannot be touched
- Suitable protective clothing and/or equipment must be worn when carrying
out the test or the repair
