Fronius Selectiva 4185 Service Manual

108
Overview "Replacing components" is divided into the following sections:
Opening the device:
- Opening the Selectiva 8 kW
- Opening the Selectiva 16 kW
Replacing components on the front panel:
- Replacing the P-display (1)
Replacing components behind the front panel:
- Replacing the 8 kW primary power module (2)
- Replacing the 16 kW primary power module (2)
- Replacing the P-control/CFM PC board (3)
- Replacing the 8 kW axial fan (4)
- Replacing the 16 kW axial fan (4)
- Replacing the 8 kW mains cable (5)
- Replacing the 16 kW mains cable (5)
- Replacing the charger lead (6)
- Replacing fuses (7)
- Replacing the secondary diodes (8)
- Replacing temperature sensor (9)
(1)
(4) (5) (2) (8) (3) (9)(7)(6)

Fronius Selectiva 4185 Specifications

General

Brand	Fronius
Model	Selectiva 4185
Category	Battery Charger
Language	English
