Fronius Selectiva 4185 Service Manual

169
EN
42,0409,5166 Front foil Selectiva
42,0405,0907 Display spacer frame 4 LED
4,071,053,Z PC BOARD P-DISPLAY tested
42,0405,0957 Cover 4 LED 69.5x22x11.5mm TPE black
43,0001,1430,Z Primary power mod. 16kW test.
42,0405,1107 Cable gland, plug-in 45.7x28.6mm
43,0002,0484 Switch 10mA 12V 2-pin Switch
43,0006,0186 Pump electrolyte circulation 230V 20l/min.
33,0030,0132 Auto-transf. Air Puls 400v of 230V 50/60Hz
42,0405,2011 Cover USB A 90.85x32.7x15mm Flamex TF70 anthracite
42,0405,2013 DC grommet 25+35 48x41.5x24mm Flamex TF50 anthracite
43,0004,4762 Mains cable 4G6mm² 3m
43,0004,4764 Mains cable 5G6mm² 3m
42,0401,1011 PT SCREW K4x25 TORX VZ
42,0401,1113 PT screw 4x8 Torx gr Plastic screw
42,0401,1149 PT steel 5x8mm T25 PT ZnNI DIN50962
42,0401,1024 CHEESE-HEAD SCREW 7045 5x10
42,0401,1030 CHEESE-HEAD SCREW 4042 4x9
42,0401,1176 Tapping screw M5x16 7045 C Screw [metric] steel 8.8
42,0401,0446 HEXAGON SCREW 933 8X16 VZ
42,0401,0433 HEXAGON SCREW 933 6x16 VZ C
42,0401,0448 HEXAGON SCREW 933 8x20 GALV.
42,0407,0120 SPRING-RING DIN127B 8 GALV.
42,0407,0118 LOCK WASHER 127B 6 GALV.
42,0400,0233 HEXAGON NUT 934 M8 GALV.
42,0399,0018 WASHER 125 8 MS
42,0399,0002 WASHER 125A 6 MS
42,0399,0085 WASHER 134 A 8 VZ OLD NR.:42.0399.0001
42,0402,0310 N
42,0409,0020 Thermal xfr tape 25x45 oval
42,0402,0300 Air filter AirPulsPur PPI45 34x20mm
42,0405,0918 Filter cap Air-Puls 48x33.5mm TPE black
42,0300,7262 Side insul. 0.3x568x323.84mm Side insulation Selectiva
41,0001,0694 SHUNT 100μohm 5W 5%
43,0001,3407 Filmcap. 15μF 250V 10% KSø6/ø4
42,0201,3890 Adapter HL fuse Selectiva 8+16kw
42,0405,2017 Strain-rel. strip 71x22.5x17.2 Valox 357X black
43,0001,1438 BG isotope DSEI 2x101-06A PCM PCM printed isotope diode
42,0201,3891 Busbar DC + Selectiva 8+16kw
42,0405,2016 Lid transf. conn. 97x39.5x23.5 Valox 357X black
42,0201,3892 Power rail transformer Selectiva 8+16kw
43,0001,1084 THERMOSTAT TP1400
42,0407,0578 BINDER 200x4,5 bl
43,0001,3406 Protective circuit 2x47nf
41,0012,0018 FE-ring 40x25x20mm 6000
