The country setup can only be set when using the inverter for the first time. If the country
setup needs to be changed at a later date, please contact your installer / Technical Sup-
port team.
Button functions
and LED status
indicator
The status of the inverter is
shown via the operating status
LED. In the event of faults, carry
out the individual steps in the
Fronius Solar.start app.
The optical sensor is actuated by
touching with a finger.
The status of the connection is
shown via the communication
LED. To establish the connection,
carry out the individual steps in
the Fronius Solar.start app.
Sensor functions
1x = WLAN access point (AP) is opened.
Flashing blue
2x = WLAN Protected Setup (WPS) is activated.
Flashing green
3 seconds (max. 6 seconds) = the service notification is ter-
minated and the key lock is deactivated.
Lights up yellow
LED status indicator
The inverter is operating correctly.
Lights up green
The inverter starts.
Flashing green
The inverter is in standby, is not operational (e.g. no feed-in at
night) or is not configured.
Lights up yellow
The inverter indicates a non-critical status.
Flashing yellow
89
EN
