Opening the Housing
Opening the
housing
DANGER!
Risk of death due to contact with live components when the device is open!
An electric shock will cause serious injury or death.
► If the device is switched on with the housing open, do not touch the components inside
the housing.
► Use only suitable measuring probes or test probes.
Remove 2 5x18 TX25 screws (1) on
the control panel.
Fold the control panel (2) to the side.
Remove 4 5x18 TX25 screws (3) on
the front of the device and remove the
housing feet.
