57
EN-US
Manual Metal Arc Welding
Safety
WARNING!
Danger due to incorrect operation.
This can result in severe personal injury and damage to property.
► Do not use the functions described here until you have fully read and understood the
Operating Instructions.
► Do not use the functions described here until you have fully read and understood all of
the Operating Instructions of the system components, especially the safety rules.
WARNING!
An electric shock can be fatal.
If the power source is connected to the grid during installation, there is a danger of serious
personal injury and property damage.
► Only carry out work on the device when the power source's power switch is in the - O
- position.
► Only carry out work on the device when the power source has been disconnected from
the grid.
Preparation Set the power switch to - O -
Unplug mains plug
Remove TIG welding torch
Insert grounding cable and lock:
- For manual metal arc DC- welding in the (+) current socket
- For manual metal arc DC+ welding in the (-) current socket
Connect the other end of the grounding cable to the workpiece
Insert electrode cable and lock by turning to the right:
- For manual metal arc DC- welding in the (-) current socket
- For manual metal arc DC+ welding in the (+) current socket
Insert mains plug
CAUTION!
Danger of injury and damage from electric shock.
When the power switch is switched to position - I -, the rod electrode in the electrode holder
is live.
► Ensure that the rod electrode is not touching any people or electrically conductive or
grounded parts (housing, etc.).
Set the power switch to - I -
All displays on the control panel briefly illuminate.
1
3
4
6
7
8
