67
EN-US
TIG Setup Menu
Parameters in the
TIG Setup menu
The following parameters are available through the TIG Setup menu:
Electrode diameter
0.0 - 3.2 mm
Factory setting: 2.4 mm
Spot welding time/interval welding time
off / 0.05 - 25 s
Factory setting: off
If a value has been set for the setup parameter SPt, this means that 2-step mode corre-
sponds to the spot welding mode.
The spot welding special display illuminates on the control panel if a value for the
spot welding time has been entered.
Interval pause time
This parameter is only available in 2-step mode and when the "SPt" parameter is activated.
off / 0.5 - 25 s
Factory setting: off
Tacking
Tacking function - duration of the pulsed welding current at the start of the tacking process
off / 0.1 - 9.9 s / on
Factory setting: off
on
The pulsed welding current remains present until the end of the tacking process
0.1 - 9.9 s
The set time begins with the UpSlope phase. After the set time has passed, further welding
is carried out at a constant welding current. Set pulse parameters are available if applica-
ble.
off
Tacking function is switched off
