97
EN-US
Explanation of
Footnotes
/EF Power source with mains cable fitted
/np Power source with mains cable fitted and without plug for the public grid
/B Power source with mains cable to plug in
1) On a public grid with 230 V and 50 Hz
2) D.C. = duty cycle
3) PCC = interface to the public grid
Degree of protection IP 23
Type of cooling AF
Insulation class A
EMC device class (according to EN/IEC
60974-10)
A
Overvoltage category III
Pollution degree according to IEC60664 3
Ambient temperature -10 °C - +40 °C / +14 °F - +104 °F
Storage temperature -25 °C - +55 °C / -13 °F - +131 °F
Dimensions l x w x h 435 x 160 x 310 mm / 17.1 x 6.3 x 12.2 in.
Weight 9.9 kg / 21.8 lb.
Marks of conformity CE, CSA
Safety symbol S
Max. shielding gas pressure 5 bar / 73 psi
Noise emissions (L
WA
) 68.0 dB (A)
