Fronius TransTig 4000 User Manual

101
EN
MagicWave
4000 / 5000
Primary continuous power (100% d.c.
2)
)
3 x 400 - 460 V
3 x 200 - 240 V
1 x 200 - 240 V
4.8 kVA
4.4 kVA
3.9 kVA
5.1 kVA
4.9 kVA
4.3 kVA
Cos phi 0,99 0,99
Welding current range (3-phase)
TIG 3 - 250 A 3 - 300 A
Electrode 10 - 250 A 10 - 300 A
Welding current range (single phase)
TIG 3 - 220 A 3 - 220 A
Electrode 10 - 180 A 10 - 180 A
Welding current at 3 x 400 - 460 V
10 min/40 °C (104 °F) 35% d.c.
2)
- 300 A
10 min/40 °C (104 °F) 40% d.c.
2)
250 A -
10 min/40 °C (104 °F) 100% d.c.
2)
180 A 190 A
Welding current at 3 x 200 - 240 V
10 min/40 °C (104 °F) 30% d.c.
2)
- 300 A
10 min/40 °C (104 °F) 35% d.c.
2)
250 A -
10 min/40 °C (104 °F) 100% d.c.
2)
170 A 180 A
Welding current at 1 x 200 - 240 V
10 min/40 °C (104 °F) 40% d.c.
2)
220 A -
10 min/40 °C (104 °F) 50% d.c.
2)
- 220 A
10 min/40 °C (104 °F) 100% d.c.
2)
150 A 160 A
Open circuit voltage 89 V 89 V
Working voltage
TIG 10.1 - 20.0 V 10.1 - 22.0 V
Electrode 20.4 - 30.0 V 20.4 - 32.0 V
Striking voltage (U
p
) 10 kV 10 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23 IP 23
Type of cooling AF AF
Insulation class B B
EMC emission class
(in accordance with EN/IEC 60974-10)
AA
Dimensions L x W x H (with handle) 560 / 250 / 435 mm
22.0 / 9.8 / 17.1 in.
560 / 250 / 435 mm
22.0 / 9.8 / 17.1 in.
Weight 28.2 kg
62.17 lb.
30 kg
66.14 lb
Mark of conformity S, CE S, CE
MW 2500 MV MW 3000 MV
MW 4000 MW 5000
Mains voltage 3 x 400 V 3 x 400 V
Mains voltage tolerance ± 15 % ± 15 %
Mains frequency 50/60 Hz 50/60 Hz
