Fronius TransTig 4000 User Manual

102
MagicWave
4000 / 5000 MV
Mains fuse protection (slow-blow) 35 A 35 A
Mains connection
1)
Restrictions possible Restrictions possible
Primary continuous power (100% d.c.
2)
) 15.5 kVA 17.9 kVA
Cos phi 0,99 0,99
Welding current range
TIG 3 - 400 A 3 - 500 A
Electrode 10 - 400 A 10 - 440 A
Welding current at
10 min/40 °C (104 °F) 40% d.c.
2)
- 500 A
10 min/40 °C (104 °F) 45% d.c.
2)
400 A -
10 min/40 °C (104 °F) 60% d.c.
2)
365 A 440 A
10 min/40 °C (104 °F) 100% d.c.
2)
310 A 350 A
Open circuit voltage 90 V 90 V
Working voltage
TIG 10.1 - 26.0 V 10.1 - 30.0 V
Electrode 20.4 - 36.0 V 20.4 - 37.6 V
Striking voltage (U
p
) 9.5 kV 9.5 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23 IP 23
Type of cooling AF AF
Insulation class F F
EMC emission class
(in accordance with EN/IEC 60974-10)
AA
Dimensions L x W x H (with handle) 625 / 290 / 705 mm
24.6 / 11.4 / 27.8 in.
625 / 290 / 705 mm
24.6 / 11.4 / 27.8 in.
Weight 58.2 kg
128 lb.
58.2 kg
128 lb.
Mark of conformity S, CE S, CE
MW 4000 MW 5000
MW 4000 MV MW 5000 MV
Mains voltage 3 x 200 - 240 V
3 x 380 - 460 V
3 x 200 - 240 V
3 x 380 - 460 V
Mains voltage tolerance ± 10 % ± 10 %
Mains frequency 50/60 Hz 50/60 Hz
Mains fuse protection (slow-blow) 63/35 A 63/35 A
Mains connection
1)
Restrictions possible Restrictions possible
Primary continuous power (100% d.c.
2)
) 13.9 kVA 16.5 kVA
Cos phi 0,99 0,99
Welding current range
TIG 3 - 400 A 3 - 500 A
Electrode 10 - 400 A 10 - 440 A

Fronius TransTig 4000 Specifications

General

Brand	Fronius
Model	TransTig 4000
Category	Welding System
Language	English
