Fronius TransTig 4000 User Manual

106
TransTig
4000 / 5000
Degree of protection IP 23 IP 23
Type of cooling AF AF
Insulation class B B
EMC emission class
(in accordance with EN/IEC 60974-10)
AA
Dimensions L x W x H (with handle) 560 / 250 / 435 mm
22.0 / 9.8 / 17.1 in.
560 / 250 / 435 mm
22.0 / 9.8 / 17.1 in.
Weight 25.9 kg
57.10 lb.
25.9 kg
57.10 lb.
Mark of conformity S, CE S, CE
TT 2500 MV TT 3000 MV
TT 4000 TT 5000
Mains voltage 3 x 400 V 3 x 400 V
Mains voltage tolerance ± 15 % ± 15 %
Mains frequency 50/60 Hz 50/60 Hz
Mains fuse protection (slow-blow) 35 A 35 A
Mains connection
1)
Restrictions possible Restrictions possible
Primary continuous power (100% d.c.
2)
) 11.8 kVA 15.1 kVA
Cos phi 0,99 0,99
Welding current range
TIG 3 - 400 A 3 - 500 A
Electrode 10 - 400 A 10 - 500 A
Welding current at
10 min/40 °C (104 °F) 40% d.c.
2)
- 500 A
10 min/40 °C (104 °F) 45% d.c.
2)
400 A -
10 min/40 °C (104 °F) 60% d.c.
2)
365 A 450 A
10 min/40 °C (104 °F) 100% d.c.
2)
310 A 350 A
Open circuit voltage 86 V 86 V
Working voltage
TIG 10.1 - 26.0 V 10.1 - 30.0 V
Electrode 20.4 - 36.0 V 20.4 - 40.0 V
Striking voltage (U
p
) 9.5 kV 9.5 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23 IP 23
Type of cooling AF AF
Insulation class F F
EMC emission class
(in accordance with EN/IEC 60974-10)
AA
Dimensions L x W x H (with handle) 625 / 290 / 475 mm
24.6 / 11.4 / 18.7 in.
625 / 290 / 475 mm
24.6 / 11.4 / 18.7 in.
Weight 39.8 kg
87.7 lb.
39.8 kg
87.7 lb.
Mark of conformity S, CE S, CE
