Fronius TransTig 4000 User Manual

103
EN
TransTig 2200
Welding current at
10 min/40 °C (104 °F) 40% d.c.
2)
- 500 A
10 min/40 °C (104 °F) 45% d.c.
2)
400 A -
10 min/40 °C (104 °F) 60% d.c.
2)
360 A 440 A
10 min/40 °C (104 °F) 100% d.c.
2)
300 A 350 A
Open circuit voltage 90 V 90 V
Working voltage
TIG 10.1 - 26.0 V 10.1 - 30.0 V
Electrode 20.4 - 36.0 V 20.4 - 37.6 V
Striking voltage (U
p
) 9.5 kV 9.5 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23 IP 23
Type of cooling AF AF
Insulation class F F
EMC emission class
(in accordance with EN/IEC 60974-10)
AA
Dimensions L x W x H (with handle) 625 / 290 / 705 mm
24.6 / 11.4 / 27.8 in.
625 / 290 / 705 mm
24.6 / 11.4 / 27.8 in.
Weight 60 kg
132.30 lb.
60 kg
132.30 lb.
Mark of conformity S, CE, CSA S, CE, CSA
MW 4000 MV MW 5000 MV
Mains voltage 230 V
Mains voltage tolerance -20 % / +15 %
Mains frequency 50/60 Hz
Mains fuse protection (slow-blow) 16 A
Mains connection
1)
No restrictions
Primary continuous power (100% d.c.
2)
) 3.0 kVA
Cos phi 0,99
Welding current range
TIG 3 - 220 A
Electrode 10 - 180 A
Welding current at
10 min/25 °C (77 °F) 50% d.c.
2)
220 A
10 min/25 °C (77 °F) 60% d.c.
2)
200 A
10 min/25 °C (77 °F) 100% d.c.
2)
170 A
10 min/40 °C (104 °F) 40% d.c.
2)
220 A
10 min/40 °C (104 °F) 60% d.c.
2)
180 A
10 min/40 °C (104 °F) 100% d.c.
2)
150 A
Open circuit voltage 84 V
Working voltage
TIG 10.1 - 18.8 V
Electrode 20.4 - 27.2 V
Striking voltage (U
p
) 9.5 kV
