Waiting
The Wattpilot is waiting for cheap electricity from a
photovoltaic system or electricity provider, or the char-
ging timer is active.
-
The LEDs flash blue in the number of amperes set.
Wait for car
The Wattpilot recognises the connected vehicle and the
set charging parameters. Charging has been enabled by
the charging station but not yet started by the car.
-
A few yellow LEDs light up when the charging cur-
rent is low.
-
Several/all yellow LEDs light up when the charging
current is high.
1-phase charging
The Wattpilot is carrying out 1-phase (230 V) charging
with low to high charging current.
-
One series of blue LEDs moves in a clockwise direc-
tion.
-
The level of charging current is indicated by the
number of LEDs and the speed of rotation.
3-phase charging
The Wattpilot is carrying out 3-phase (400 V) charging
with low to high charging current.
-
Three series of blue LEDs move in a clockwise direc-
tion.
18
