2-3
2.2 Basket Lift Assembly and Associated Parts cont.
ITEM PART # COMPONENT
Basket Lift Assemblies (see Note 1 in illustration)
106-1808SP Basket Lift Assembly, 100-120VAC w/Relay (Items 1-20) shown
106-1805SP Basket Lift Assembly, 200-220VAC w/Relay (Items 1-20) shown
* 106-1806SP Basket Lift Assembly, 230-250VAC w/Relay (Items 1-20) not shown
1 810-1012 Rod, Basket Lift
2 813-0035 Bushing, Bronze
3 807-2513 Capacitor, 12.5 μFd 330VAC
4 901-8499 Chassis, Left Basket Lift
5 902-8499 Chassis, Right Basket Lift
6 807-0159 Connector, 12-Pin Female
7 900-5529 Gusset, Basket Lift Motor
8 812-0442 Insulation, Microswitch
9 807-2572 Microswitch
10 806-5964SP Motor Assembly, 208-240VAC Modular Basket Lift
11 200-2942 Mount, Modular Basket Lift
12 807-1683 Relay, 12VDC
13 Resistor Assembly
806-8530SP
100-120V Modular Basket Lift (see Note 2 in illustration)
106-2770SP 208-220VAC Modular Basket Lift
* 106-2771SP 230-250VAC Modular Basket Lift
14 809-0082 Ring, Bushing Retainer
15 910-4776 Cover, Modular Basket Lift Rear S/S (Use 900-4776 for Mild Steel)
16 809-0127 Screw, ¼-20 X ½-inch Slotted Round Head
17 823-7986 Arm, Left Basket Lift
18 823-7987 Arm, Right Basket Lift
19 810-0179 Button, Plug
20 108-2743SP Roller Assembly, Basket Lift
21 108-2860 Mount, Basket Lift Roller
22 810-0194 Roller, Basket Lift
23 810-0374 Spacer, Basket Lift Roller
24 809-0508 Bolt, ¼-20 X 1¼ -Inch
25 823-7980 Guide, Basket lift Left
26 823-8023 Guide, Basket lift Right
27 809-0990 Nut, ¼-20 Cap
* 824-1477 Tray, Drip Right
* 824-1476 Tray, Drip Left
Wire Assemblies
* WIR-0166SP Wire Bundle, 200-250VAC Basket Lift w/Relay
* 106-5962 Wiring Harness, RE Series Electric Basket Lift (Plugs into Item 6)
* 106-6640 Wiring Harness, RE Series Electric Basket Lift SSR (Plugs into Item 6)
* Not illustrated.
